Description
Krona Koblenz Atomika Karakter K8120
Sold : each
Finish : Satin Chrome
Availability
3-6 weeks from date of order
Product Information
Usage: Commercial and residential doorsets
Weight Rating
120kg – 3 Hinges
120kg – 2 Hinges
Material
Steel
Minimum Door Thickness
36 mm
Additional Information
A concealed hinge made of highly resistant steel for flush doors with wooden, steel and aluminium frames. Load capapcity up to 120kg, 180 opening angle with the minimum door thickness of 36mm. Wear-resistant bushings, lubrications/maintenance not required.
Three-dimensionally adjustable, all adjustments are independent, assisted and self supporting.
Adjustments: horizontal +3,0/-2,0mm, vertical =+/-3,0mm, Planar +/- 1,0mm
Cover caps are supplied with this product
